Mechanical Brakes

2510M Mechanical Brakes

  • Capable of 2,500 Lbs. of clamp force
  • Economical heat treated stamped steel construction
  • Zinc finish resists rust and corrosion
  • Large friction area for extended pad life
  • Choice of CW or CCW lever actuation
  • Can be fixed or floating mounted
  • Mount Bracket optional, consult Hayes for available options
Send a Request

  • Medium duty mechanical brake

  • Weight
    2.8 Lbs.
    Rotor Diameter
    5 To 8.5 In
    Rotor Thickness
    .156 To .375 In
    Lining Type
    Non-Asbestos Organic, Sintered
    Total Lining Area
    11 Sq. In.
    Usable Lining Thicknes Per Pad
    .13 In.
